For tool making and mold making:
Tool steel by Stahl Krebs.
In order to distinguish between tool steel and structural steel, one looks at the application: Tool steel is not only used for the production of tools, but also for standard parts and shapes. The optimal composition is determined and developed using computer-technology. For this purpose, software is used with which the quantity ratios can be determined and optimized accurately.
Examples of
applications
-
Tools
-
Hand tools
-
Parts
-
Forms
Toolsteel
Extensive delivery program.
Matching tool steel.
Whether unalloyed or alloyed cold working steel or high-speed steel in raw or processed form – our range of tool steels is very comprehensive. Depending on the purpose for which you want to use the steel, we have the right material.
We supply tool steel made of forged bar steel and rolled plates for die forging and mold making. Hot and cold working steel is just as much part of our program as die steel - here we also offer ESU quality - and plastic mold steel. Per customer request, we deliver with transport bores or dovetailing as well as processing according to customer drawings.
Our
tool steels
-
The following table provides you with an excerpt of our available material grades with corresponding quality standards.
Steel for molding elements
| MATERIAL NUMBER |
MATERIAL DESCRIPTION |
QUALITY STANDARD |
|---|---|---|
| 1.1730 | C45U | EN ISO 4957 |
Corrosion-resistant plastic mold steel
| MATERIAL NUMBER |
MATERIAL DESCRIPTION |
QUALITY STANDARD |
|---|---|---|
| 1.2083 | X40Cr14 | EN ISO 4957 |
Hot-working steel | Dies
| MATERIAL NUMBER |
MATERIAL DESCRIPTION |
QUALITY STANDARD |
|---|---|---|
| 1.2344 | X40CrMoV5-1 | EN ISO 4957 |
| 1.2345 | X50CrMoV5-1 | |
| 1.2363 | X100CrMoV5 | EN ISO 4957 |
| 1.2365 | 32CrMoV12-28 | EN ISO 4957 |
| 1.2367 | X38CrMoV5-3 | EN ISO 4957 |
| 1.2410 | 74CrW1 | |
| 1.2567 | 30WCrV17-2 | |
| 1.2714 | 55NiCrMoV7 | EN ISO 4957 |
| 1.2744 | 57NiCrMoV7-7 | |
| 1.2889 | X45CoCrMoV5-5-3 |
Injection molding die steel
| MATERIAL NUMBER |
MATERIAL DESCRIPTION |
QUALITY STANDARD |
|---|---|---|
| 1.2343 | X37CrMoV5-1 | EN ISO 4957 |
| 1.2344 | X40CrMoV5-1 | EN ISO 4957 |
Cold working steel | Cuts | Embossing Tools | Machine Knives | Scissors
| MATERIAL NUMBER |
MATERIAL DESCRIPTION |
QUALITY STANDARD |
|---|---|---|
| 1.2067 | 102Cr6 | EN ISO 4957 |
| 1.2080 | X210Cr12 | EN ISO 4957 |
| 1.2210 | 115CrV3 | |
| 1.2235 | 80CrV2 | EN 10132-4 |
| 1.2305 | 102CrMo6 | |
| 1.2316 | X38CrMo16 | EN ISO 4957 |
| 1.2361 | X91CrMoV18 | |
| 1.2379 | X153CrMoV12 | EN ISO 4957 |
| 1.2436 | X210CrW12 | EN ISO 4957 |
| 1.2510 | 100MnCrW4 | |
| 1.2542 | 45WCrV7 | |
| 1.2550 | 60WCrV8 | EN ISO 4957 |
| 1.2601 | X165CrMoV12 | |
| 1.2631 | X50CrMoW9-1-1 | |
| 1.2721 | 50NiCr13 | |
| 1.2738 | 40CrMnNiMo8-6-4 | EN ISO 4957 |
| 1.2842 | 90MnCrV8 | EN ISO 4957 |
Mold steel | Cold and hot work
| MATERIAL NUMBER |
MATERIAL DESCRIPTION |
QUALITY STANDARD |
|---|---|---|
| 1.2767 | 45NiCrMo16 | EN ISO 4957 |
| 1.2826 | 60MnSiSiCr4 | |
| 1.2833 | 100V1 | |
| 1.2838 | 145V33 |
